19" (483 mm wide) rack
mounting
yes
depth (build in) in mm 290
power supply 100 - 240 VAC
output power RMS 100 volts in
watts
120
dynamic output power 100
volts in watts
120
output power tappings 70 - 100 volts - 4 ohms
MIC inputs balanced 3
line input unbalanced 4
priority switch 2
chime yes
priority output 1
power amp topology class-D
cooling system convection
applicable low impedance yes
height- rack units (1U=44 mm)
in U
2
depth (incl front) in mm 300
power consumption (max) in
watts
160
output power RMS 4 ohms in
watts
120
minimum impedance load in
ohms
4
zone outputs 1
inputs with Phantom power 2
tone control yes
VOX mute yes
emergency input 1
priority levels 4
frequency response (in Hz) 60 - 20 k
applicable in 100V yes
Net weight product (kg) 5
